background image

11

Workstation Series User’s Guide

3

Connections and Setup

Connections

Power

To connect the printer to a viable power source, please follow the steps below.

Caution:

Ensure the printer power switch is off before connecting the AC power and

data/network connectivity cables to the printer.

Caution:

Adhere to all environmental requirements when installing and using the printer.

Use of the product in an unsuitable environment may affect print quality and the
durability of the printer and may void the manufacturer’s warranty.

1. Place the printer on a suitable level surface capable of securely supporting 8lbs.

2. Connect the AC power cord to the power supply brick

3. Connect the AC power cord from the power supply brick to AC utility power.

4. Connect the DC power cord from the power supply brick to the printer power jack.

5. Using the power switch, turn on the printer.

During power-up, the LEDs indicate the status of the printer.

Table 1: Power-Up - LED Status

Data

Printer data connectivity can be accomplished by the following standard or optional
interfaces:

USB

Ethernet/Network

Serial (Optional)

Connect the appropriate interface cables for your network configuration.

Action

Green LED

Red LED

Printer begins to power-up

Solid

Solid

Printer indicates powering up

Double Blink

Double Blink

Printer is online

Solid

Off or slow blink which
indicates cover open or an
uncalibrated condition.
