3 | Connections and Setup
Workstation Series User’s Guide
14
5. Route the paper under the support bracket guides.
Figure: 3 - 3 Support Bracket Guides
6. Close and latch the printer cover.
7. Feed the paper to find top-of-form.
Note:
When installing new media, perform a paper calibration to ensure the printer finds
the top-of-form.
Media Loading - Peel and Present
The peel and present option allows for the media labels to peel at the peel bar while the
label backing routes away from the labels.
Left Guide
Right Guide
