19
4.8.2 LAN interface
A standard RS232 interface is available through a DB9 female connector:
- It permits controlling the device
- It permits updating the device
Data Rate: 1200 to 115200 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control by default.
DTR & RTS needed for firmware upgrade.
4.8 Communication specifications
4.8.1 Serial interface
4.8.2.1 Protocol
4.8.2.2 IP address
4.8.2 LAN interface
Protocol Availability
TCP Yes
UDP Yes
Address allocation Availability
Static user defined address Yes
A standard LAN interface is available through a RJ-45 connector
- It permits controlling the device
- It permits transferring configuration
- It permits connectivity with the RCS² application
- It permits updating the device
Default IP address: 192.168.2.140
