66
PIP configuration
1. Click on the Image tab of the RCS interface.
The empty Image screen will appear on
screen.
2. By clicking on the drop-down menu
in the Preview section, situated
next to the layer you wish to use
as a PIP, you will access the image
parameters of the PIP source you select
( # 1 to # 12)
3. Set the desired PIP attributes (size,
position, zoom, border, transparency...).
4. Click on the Image tab to return to the main
screen.
Working with Frames
It is possible to store up to 8 frames in the
OPS300 non volatile memory. Frames are
mainly used as backgrounds in a typical show
or event setup, and can be recorded from any
of the 8
OPS300 sources and called back at
the click of a single button.
* NOTE * : to memorize a frame, select an
input, and take it to the Main screen. Once the
frame is displayed on your Main output, it is
then possible to store it to the
OPS300 non
volatile memory.
* NOTE * : frames may be used only one at
a time. A frame may not be used as a Live
Background.
