5.2.1.1 - Static & combined modes
After calibration as per
STEEL OR ALUMINUM WHEEL RIMS. SPRUNG COUNTERWEIGHTS
, it is possible to modify the
position of the correction weights using the buttons.
►
STATIC: Select by pressing (5E)
Balancing of light alloy rims with application of adhesive weights
on the shoulders of the rims.
Combined balancing: adhesive weight on the outside and clip-on
weight on the inside.
Combined balancing: adhesive weight on the inside and clip-on
weight on the outside.
5.2.2 - Rims with internal counterweight ►
Slide out the gauge on the LH side, at the point where a weight is to be fi tted. Wait for the “beep”. Slide it out further
towards the RH side and wait for a second “beep”. The wheel balancer automatically identifi es ALUS mode.
Counterweight position automatically suggested .
(5I) can be used to set the alternative position indicated.
Adhesive
weights
position
