CEMB USA C71_2 evo (D) - Manual (Page 14)

I 0637 - 14
9
10
b
a
d
GB
6.3 - Manual dimension presetting (Use only in particular cases or for test)
6.3.1 - Steel wheel rims (use for setting dimensions in AUTOCALIBRATION )
►
►
- Setting:
Press or
Set with the rated width that, in general, is shown
on the rim, or measure width “b” with the calliper gauge supplied.
Press the button for more than 2 seconds
Preset using distance “a” for the inside of the wheel
from the machine.
Preset using the nominal diameter “d” indicated on
the tyre
N.B.: This setting is also valid for the correction modes
indicated at “ STATIC & COMBINED MODES ”.
▪
▪
▪
▪
6.3 .2 - ALUS rims ►
Reading point
