CEMB USA C65 (E) User Manual
Page 11
I 0206 - 11
6
7
5
2
3
4
GB
Press F1 to re-lower the guard and repeat the width measurement. Press F2 to go to the dimensions
panel for manual insertion of the width measurement.
The calibration performed as such is necessary for modes AL1,2,3,4,CTS,Static, Dynamic.
Manually presetting is possible by using the push buttons as described in
TO CALL MEMORIZED MEASUREMENTS
.
- Wheel ALU-S (correction from the inside for two balancing planes with direct calibration):
After the measurement carried out for the inside FI as described in fig. 9, pull out the gauge further to
memorize the data for the outside FE: keep this position for at least 2 seconds.
The counterweight symbols change colour.
When the acoustic signal is enabled (see
ACOUSTIC SIGNAL
), the acquisition is accompanied by a “beep”.
The following buttons are enabled:
Fig. 9
Select the dimensions presetting in manual mode screen.
/
Return to initial screen.
Balancing spin
AUTOMATIC WIDTH MEASUREMENT OPTION enabled:
The button LT (LIGHT TRUCK) serves for improved dimensional calibration of
large size wheels such as off-the-road vehicles, trucks, or wheels which project
by a large amount from the rim. Press button LT after the distance measurement
and immediately upon lowering the wheel guard for width measurement. The
optional feature is automatically disabled upon measuring another wheel.
5.3.2 TO CALL MEMORIZED MEASUREMENTS
Press the button with relative user’s name:
- when
is pressed, the stored measurements will be called
(
USER MEMORIZATION
) while disregarding other measurements made in
the meantime.
- when
2
is pressed, the currently preset dimensions are saved.
