20
Use and maintenance manual Rev. 10-2009
ENGLISH
6.2 UNBALANCE OPTIMIZATION
The symbol is displayed automatically for static unba-
lance exceeding 30 grams (1.1 oz). The program allows
reducing the total unbalance of the wheel by compensating,
when possible, the unbalance of the tyre with that of the rim.
It requires two spins with rotation of the tyre on the rim in the
second spin.
Press + after a fi rst spin and follow the
instructions appearing on the monitor.
7. Setup
The Setup screen provides the user with many possibilities
required for presetting the machine according to his own
requirements. Such settings remain unaltered even when
the machine is switched off.
The following buttons are enabled:
: return to previous window
: return to Measurement screen
from to : for selection of the parameter.
7.1 LANGUAGE
This function allows selecting the language to be used for
displaying descriptive and diagnostic messages regarding
machine operation.
7.2 UNIT OF UNBALANCE MEASUREMENT
It is possible to select whether to display the unbalance
values expressed in grams or ounces.
7.3 TOLERANCE
(also see CORRECTION METHOD)
This is the unbalance threshold below which the word “OK”
instead of the unbalance value appears on the screen at
the end of the spin:
The tolerance varies based on the correction method
selected.
In the case of IC (Intelligent Correction), set the static
tolerance limit and the average weight of a reference
wheel of 6” in width and 15” in diameter.
