Week programme
Release R.1.3 UK 57
gis
The cursor moves to the minute digits, which will blink. See Figure 8.12 .
7. Use H and L to select the minutes. In the example this is 45 .
Confirm with E.
The cursor moves to the water temperature. See
Figure 8.13 .
Setting the water temperature
8. Use H and L to select the water temperature. In the example this is 75ÉC.
Confirm with E.
The cursor moves to
PUMP ON . See Figure 8.14 .
Setting program-controlled pump
9. If required, a pump can be controlled during the period. Use H and L to
select PUMP ON . The pump ensures a regular circulation of hot water in
the hot water pipes. You can skip this step if you there is no pump in your
hot water circuit.
Confirm with E.
The cursor moves to SAVE . See Figure 8.15 .
10. Confirm with E.
The display shown in Figure 8.16 appears.
11. If you wish, use L to scroll to another day, and change more switch-on and
switch-off times. Simply repeat steps 3 through 10 .
12. After changing all desired switch-on and switch off times, you can start
running the week program:
-
Scroll with L to
START OPERATION
.
Confirm with E.
8.5.4 Adding times to a week program
The menu to INSERT switch-on and switch-off times into a week program is
reached via:
1. B:
WEEK PROGRAM | PROGRAM OVERVIEW .
Confirm with E.
ON SU 08:15
OFF SU 12»15
Tset 65ÉC
PUMP ON SAVE
Figure 8.12 Setting switch-off
minutes in week program
ON SU 08:15
OFF SU 12:45
Tset»65ÉC
PUMP ON SAVE
Figure 8.13 Setting water
temperature in week program
ON SU 08:15
OFF SU 12:45
Tset 75ÉC
PUMP ON SAVE
Figure 8.14 Setting the pump in
week program
ON SU 08:15
OFF SU 12:45
Tset 75ÉC
PUMP ON »SAVE
Figure 8.15 Save week
program
DAY TIME Tset
ON »SU 08:15 75ÉC P
OFF SU 12:45
ON MO 00:00 65ÉC P
OFF MO 23:59
ON TU 00:00 65ÉC P
OFF TU 23:59
Figure 8.16 Add week program
WEEK PROGRAM
START OPERATION
^»PROGRAM OVERVIEW
È
Figure 8.17 Inserting a week
program
