56 Instruction Manual BFC
8
gis
The display now shows the menu for the week program, see Figure 8.7 . With
the default setting, the program switches on and off every day at 00:00 and
23:59 hours respectively, the water temperature is 65ºc and the pump is
switched on (
P ).
Example
As an example, we will set the switch-on time for Sunday to 08:15 hours, and
the matching switch-off time to 12:45 hours. The water temperature will be set
to 75ºC and the pump will run continuously.
The following settings are entered one by one via the menu: the switch-on time,
the switch-off time, the desired water temperature, and the state of the program-
controlled pump.
Setting the switch-on time
2. Bring the cursor to
SU and press E. The sub-menu shown in
Figure 8.8 will appear. The day indicated by the » will blink.
3. Use H and L to select the day desired. In the example, this is SU (Sunday).
Confirm with E.
The cursor moves to the hour digits, which will blink. See Figure 8.9 .
4. Use H and L to select the hour. In the example this is 08 .
Confirm with E.
The cursor moves to the minute digits, which will blink. See Figure 8.10 .
n Remark
Because the switch-off time can never be earlier than the switch-on time, the
switch-off time setting is automatically adjusted with the switch-on time.
5. Use H and L to select the minutes. In the example this is 15 .
Confirm with E.
The cursor moves to the switch-off hour digits, which will blink. See
Figure 8.11 .
Setting switch-off time
6. Use H and L to select the hour. In the example this is
12 .
Confirm with E.
DAY TIME Tset
ON »SU 00:00 65ÉC P
OFF SU 23:59
ON MO 00:00 65ÉC P
OFF MO 23:59
ON TU 00:00 65ÉC P
OFF TU 23:59
ON WE 00:00 65ÉC P
OFF WE 23:59
ON TH 00:00 65ÉC P
OFF TH 23:59
ON FR 00:00 65ÉC P
OFF FR 23:59
ON SA 00:00 65ÉC P
OFF SA 23:59
INSERT
DELETE
START OPERATION
Figure 8.7 Standard week
program
ON »SU 00:00
OFF SU 23:59
Tset 65ÉC
PUMP ON SAVE
Figure 8.8 Week programme
ON SU»08:00
OFF SU 08:00
Tset 65ÉC
PUMP ON SAVE
Figure 8.9 Setting switch-on
hours in week program
ON SU 08»15
OFF SU 08:15
Tset 65ÉC
PUMP ON SAVE
Figure 8.10 Setting switch-on
minutes in week program
ON SU 08:15
OFF SU»08:15
Tset 65ÉC
PUMP ON SAVE
Figure 8.11 Setting switch-off
hours in week program
