MoTeC Snowmobile Plug-In ECU User Manual
Page 40
32 Appendices
MoTeC
M400 Pin
Ski‐Doo Pin Function
Parameters
DIG4 B11 B21
8: Ignition Switch Logic Polarity 0
Delay 1.0
Latch 0
Note 2 – Calibration Tables
For the following pins the calibration table is available in the provided Base
Maps.
M400 Pin
Ski‐Doo Pin Function
AT1
B03 A07
Air Temperature
AT2
B04 A11
Engine Temperature
AT5
B07 A06
Oil Pressure Switch
AV1
A14 A24
Throttle Position
AV2
A15 A12
Manifold Pressure Sensor
