MoTeC Appendices 31
Calibration and Wiring Notes
Note 1 – Calibration Functions
The following pins are calibrated in the Base Maps with the function and
parameters as mentioned in the table.
M400 Pin Ski‐Doo Pin Function Parameters
Aux1 A18 not used 9: Lambda
Heater
Aux2 A01 R85 101: Fuel Pump Delay 3.0
Polarity 1
Output Mode 1
Aux3 A23 B16 3: Aux Table PWM/Switched 1
Output Mode 0
Polarity 0
Frequency 10
Minimum Duty Cycle 0
Maximum Duty Cycle 100
Hysteresis 0
Aux4 A24 V01 1:Boost Frequency 16
Polarity 0
Output Mode 0
Aux5 A31 A36 8: Idle Stepper Max Step Rate 200
Polarity 0
Aux6 A32 A35 0: Off
Aux7 A33 A38 0: Off
Aux8 A34 A37 0: Off
DIG2 B09 B09 29: Monitor Polarity 0
DIG3 B10 B07 4: Dual RPM Logic Polarity 0
Low RPM Limit 4000
RPM Rise Rate 500
Ignition Retard 0.0
