MoTeC Appendices 19
Appendices
M400M Specifications
Outputs
• 4 x Injector outputs — high or low ohm
• 4 x Ignition outputs
• 8 x Auxiliary outputs — for functions such as camshaft control, drive by
wire throttle, boost control, nitrous injection, idle speed stepper motor
and many more.
Inputs
• 8 x Analogue voltage inputs — fully configurable including custom
calibrations, e.g. to use for:
o longitudinal G force
o fuel pressure
o steering position
o lateral G force
• 6 x Analogue temperature inputs — fully configurable including custom
calibrations, e.g. to use for:
o multiple configuration maps
o extra air temperature
o extra water temperatures
o exhaust temperature
• 1 x Wideband Lambda input — for Lambda measurement and control.
• 4 x Digital/speed inputs — for use with OEM factory speed paddle
wheel and function activation e.g. launch control, anti lag and dual
RPM limit.
Communications
• 1 x CAN
• 1 x RS232 — e.g. to use with GPS. For accurate logging of speed and
position, wire the 5 Hz MoTeC GPS-G1 direct to M400 Marine ECU.
Physical
• Case size 147 x 105 x 40 mm
• Weight 900 gram
• 1 x 34 pin and 1 x 26 pin waterproof connector with gold plated
contacts.
