MoTeC Snowmobile Plug-In ECU User Manual
Page 37
MoTeC Appendices
29
M400 Pin
Ski‐Doo Pin
Function
AV6
B20
not used
AV7
B21
not used
AV8
B22
not used
DIG1
1
B08
Not used
DIG2
1
B09
B09
Tip over Switch (option)
DIG3
1
B10
B07
Reverse Position Switch
DIG4
1
B11
B21
Stop Switch
La1S
B25
L02
Lambda Sensor
La1P
B26
L08
Lambda Sensor
La2S
B12
K02
Knock Module SKM ‐ Knock Signal
La2P
B13
not used
Communications
RS232‐TX
B17
S03
Serial line to STC dash adaptor
S03
RS232‐RX
B18
S02 or G02
Serial line to STC dash adaptor
S02, OR GPS Receive Data
CAN‐LO
B24
E04
Used only for CAN Comms to PC
@1000 kbit/s
CAN‐HI
B23
E05
Used only for CAN Comms to PC
@1000 kbit/s
0V COMM B14
E01,S01,G01
0 V for CAN , GPS and STC devices
M400 Pin
Ski‐Doo Pin
Function
Additional Ski‐Doo Loom Pins
Unused
A02, A03, A04, A08, A09,
A10, A16, A17, A18, A21,
A22, A23, A26, A30, A31,
A32
