MoTeC Appendices 25
Note 2 – Calibration Tables
For the following pins the calibration table is available in the provided Base
Maps.
M400 Pin Yamaha Pin Function
AT1 B03 K02 Air Temperature
AT2 B04 K15 Engine Temperature
AT4 B06 K03 Throttle Ice Switch
AT5 B07 K08 Oil Pressure Switch
AV6 B20 K21 Oil Level Switch
Note 4 - Speed
The Snowmobile speed sensor is wired directly to the ECU. The supplied
Base Map includes a speed calibration . For more accurate speed
measurements, MoTeC recommends the use of a GPS system.
MoTeC's 5 Hz GPS-G1 (#41300) can be wired directly into the ECU's
RS232 receive port.
GPS wiring
M400 Pin GPS Pin Function
0V AUX B15 1 Bat –
RS232‐RX B18 2 RS232 GPS Data
N/C 3
5V AUX
5V ENG A09
A02 4 5 V
