MoTeC Appendices 23
M400 Pin Yamaha Pin Function
AV7
5
B21 Not used
AV8
5
B22 Not used
DIG1 B08 K04 Speed
4
DIG2
5
B09 Not used
DIG3
1
B10 Not used
DIG4 B11 Not used
La1S B25 L02 Lambda Sensor
La1P B26 L08 Lambda Sensor
La2S B12 not used Optional: Available for Knock
Module SKM ‐ Knock Signal
La2P B13 not used
Communications
RS232‐TX B17 Not used
RS232‐RX B18 not used Optional: Available for GPS
Receive Data
4
CAN‐LO B24 E04, S04 CAN line to KTC dash adaptor
CAN‐HI B23 E05, S05 CAN line to KTC dash adaptor
0V COMM B14 E01, S01 0 V for CAN and KTC devices
Additional Yamaha Loom Pins
Unused J01, J02, J13
Unused K10, K16, K17,
K18, K20, 25
K‐Line (S2) K12 K‐Line to KTC adaptor pin S2
1 – 5: See Calibration and Wiring Notes
