MoTeC Appendices 27
Pin List by Function
M400 Pin Ski‐Doo Pin Function
Power
VBAT A26 B11,S06,L05,
V02 12 V Switched (System Relay),
Lambda Heater Supply, Boost
Solenoid Supply
GND A10 B1,B2,B32,B39,
B41,R85,R87,
T85, T87 ECU Earth
GND A11 B1,B2,B32,B39,
B41,R85,R87,
T85, T87 ECU Earth
8V ENG A12 E03 8V to CAN Connector
5V ENG A02 A39,A40 5 V Sensor Supply
0V ENG B16 Not used
8V AUX A13 K04 8 V to SKM Module
5V AUX A09 G04 5 V GPS Power
0V AUX B15 A19, A20, A25,
A27, A28, L01,
K01 0 V Sensor Supply, Lambda Sensor
Ground, SKM Knock Ground
0V
COMM B14 E01,S01,G01 0 V for CAN, GPS and STC devices
Outputs
Inj1 A19 A15 Injector Cylinder 1
Inj2 A20 A33 Injector Cylinder 2
Inj3 A21 A14 Injector Cylinder 3
Inj4 A22 not used
Inj5 A27 not used Not Available in M400
Inj6 A28 not used Not Available in M400
Inj7 A29 not used Not Available in M400, M600
Inj8 A30 K03 Knock Module SKM ‐ Knock
Window
