2 Introduction
Logging and Analysis
• Internal data logging, 16 MB standard or 250 MB optional.
• Fast download via Ethernet
• Accommodating over 300 channels derived from a mixture of analogue
and digital inputs, RS232 and CAN data channels
• Configurable to use sensors from some existing engine management
systems
• Data analysis with i2 Standard or optional i2 Pro software
• Telemetry and remote logging options
Display
• Customisable screen layout, measurement units and warnings
• Configurable curved bar graph can display any channel with optional peak,
hold and shift markers
• 48 user-defined alarms, for example Low Oil Pressure, Low Fuel, Fast Lap
• Programmable overrides—particularly useful for showing values such as
lap times
• Three programmable 'pages' for Warm-up, Practice and Race ensuring the
driver is shown only the most relevant information at any given time
• Adjustable
backlight (optional)
Software
• Windows-based software designed for setup and management of the
display and data logging system
• The user can generate a configuration file offline and then send the
completed configuration to the ADL3
• Calculations including lap times, lap gain/loss, speed and distance, fuel
prediction
• Monitor active channels—view all channels live
• Sensor
zeroing
• Details editor including event, venue and vehicle details
• Extensive Help screens
• Latest software version is available free of charge from
www.motec.com/downloads
