22 Configuration
Calculations
The ADL3 has special and user definable general purpose calculations
available. They are set up from the Calculations menu.
Special Calculations
• Lap Time and Number click on the tabs to set up Lap Time, Lap Speed,
Running Lap Time, Split Lap Times, Lap Number, Laps Remaining
• Speed and Distance click on the tabs to set up Ground Speed, Drive
Speed, Wheel Slip, Lap Distance, Trip Distance, Odometer
• Lap Gain / Loss to set up a continuous indication how far behind or ahead
the vehicle is compared to a reference lap
• Gear Detection to set up Current Gear
• Fuel Prediction click on the tabs to set up Fuel Used, Fuel Usage, Fuel
Remaining, Laps Remaining, Fuel Used per Lap
• Running Min / Max to set up Minimum Corner Speed, Maximum Straight
Speed and other Min/Max values
General Purpose Calculations
• Tables to set up 2D and 3D Lookup Tables
• Timers to set up General Purpose Timers
• User Conditions to activate items such as a Thermatic Fan or Gearbox Oil
Pump
• Channel Maths to perform basic calculations on channels
• Advanced Maths to perform advanced calculations
• Bit Combine to set up a bit mask
• PID Control to set up the p
roportional, integral and derivative gain control
For details refer to ADL3 Dash Manager online help.
