MoTeC Appendices
49
Pin List by Function
Pin Name Function
Battery Power
7 BAT- Battery Negative
8 BAT+ Battery Positive
Analogue Voltage Inputs
45 AV1 Analogue Voltage Input 1
46 AV2 Analogue Voltage Input 2
47 AV3 Analogue Voltage Input 3
48 AV4 Analogue Voltage Input 4
49 AV5 Analogue Voltage Input 5
50 AV6 Analogue Voltage Input 6
19 AV7 Analogue Voltage Input 7
20 AV8 Analogue Voltage Input 8
21 AV9 Analogue Voltage Input 9
22 AV10 Analogue Voltage Input 10
23 AV11 Analogue Voltage Input 11
24 AV12 Analogue Voltage Input 12
25 AV13 Analogue Voltage Input 13
26 AV14 Analogue Voltage Input 14
1 AV15 Analogue Voltage Input 15
2 AV16 Analogue Voltage Input 16
3 AV17 Analogue Voltage Input 17
4 AV18 Analogue Voltage Input 18
5 AV19 Analogue Voltage Input 19
69 AV20 Analogue Voltage Input 20
