MoTeC Configuration
21
Note: Some inputs require the 52 I/O Upgrade to make them available.
See ADL3 Upgrades
• Select the input and click Channel (or double click the input)
• Assign a measurement channel to the input and click OK
The channel needs to be calibrated using one of two options
• Select
Load Cal if a pre-defined calibration is available
OR
• Double-click the input to enter a calibration
Other tasks:
• Change Cal – to change the calibration
• Spd Levels – only for speed inputs
• Settings – to set default
Configuring Outputs
• On
the Connections menu, click Devices
• Select device (e.g. ADL3) and then click the Output Pins tab to list all
outputs available for this product
Note: Some outputs require 52 I/O Upgrade to make them available. See
ADL3 Upgrades.
• Select the output and click Change (or doubleclick the output)
• Select a mode to make appropriate settings available
• Follow the directions on the screen and when all settings are done click
OK
Configuring Communications
• On
the Connections menu, click Communications
• Select an available communications section (CAN or RS232)
• Click
Select and choose one of the available communications templates
Comms Templates
Communication templates are available for most connected MoTeC devices.
When MoTeC releases new products, new communication templates will also
be released. These will be incorporated in the latest software versions. See
Updating ADL3 Dash Manager Software on how to update to a new software
version to make the latest communication templates available.
