Page 56: Rs232
52 Appendices
Pin
Name
Function
56
0V
Sensor 0 V
61
0V
Sensor 0 V
40
0V
Sensor 0 V
CAN Interface
71
0V
0 V CAN
72
8V
8 V CAN
74
CAN0H CAN 0 High
73
CAN0L
CAN 0 Low
76
CAN1H CAN 1 High
75
CAN1L
CAN 1 Low
Ethernet
67
E-TX+
Ethernet Transmit +
68
E-TX
– Ethernet
Transmit
–
77
E-RX+
Ethernet Receive +
78
E-RX
– Ethernet
Receive
–
RS232
79 RX RS232
Input
70 TX RS232
Output
