50 Appendices
Pin Name Function
29 AV21 Analogue Voltage Input 21
30 AV22 Analogue Voltage Input 22
31 AV23 Analogue Voltage Input 23
32 AV24 Analogue Voltage Input 24
Analogue Temp Inputs
34 AT1 Analogue Temp Input 1
35 AT2 Analogue Temp Input 2
36 AT3 Analogue Temp Input 3
37 AT4 Analogue Temp Input 4
38 AT5 Analogue Temp Input 5
39 AT6 Analogue Temp Input 6
41 AT7 Analogue Temp Input 7
42 AT8 Analogue Temp Input 8
Switch Inputs
57 SW1 Switch Input 1
58 SW2 Switch Input 2
59 SW3 Switch Input 3
60 SW4 Switch Input 4
Digital Inputs
52 DIG1 Digital Input 1
53 DIG2 Digital Input 2
54 DIG3 Digital Input 3
55 DIG4 Digital Input 4
Speed Inputs
63 SPD1 Speed Input 1
