Section 2: Installation and Wiring
The Driver module should be mounted inside a grounded, metal enclosure to
provide environmental, electromagnetic interference and safety protection.
For safety, an interlock switch should be fitted to the Controller cabinet door such
that when opened, power is disconnected from the system.
A multi-conductor cable needs to be provided to connect the Driver to the Flash
Head.
SYSTEM BLOCK DIAGRAM
Multi-way connection
cable
Flash
Head
Power In
Enclosure/Cabinet
Alarm
Outputs
Control
Signals
