MULTI-GARD
INSTALLATION PROCEDURES
www.carlonsales.com
2.
Assemble next section of Multi-Gard by applying Carlon Quick-Set™
Cement to the outside of the plain end. Then, push the plain end into the
belled end, checking for print line alignment.
3.
Screw a #10 hex head self tapping screw (refer to chart for length)
approximately 3" and 4" from the end of bell at approximately 90°. A total
of 8 screws will give the joint tensile strength given in the table below.
Repeat procedures 2 and 3 on each Multi-Gard PVC section.
Multi-Gard PVC Sections
Part No.
Description Length
Screw
Length
Joint
Tensile lbs.
Outer
Dim.
Pkg.
Qty.
Wt. per
100 Ft.
MFSS4S-
020
Type 40 4cell
20'
3/4"
5000
4.5
960'
338
MFSS3S-
020
Type 40 3-
cell
20'
3/4"
5000
4.50
960'
340
MDSS4S-
020
Type 80 4-
cell
20'
3/4"
5000
4.75
760'
450
MDSS3S-
020
Type 80 3-
cell
20'
3/4"
5000
4.75
760'
452
Bore Accessories
Part No.
Description
Pkg. Qty Wt. Ea. (lbs.)
MAG4
4.25 - 4.487 Meshgrip (7,000 wk. load)
58"
1
2.7
VC9982 Carlon Quick-Set Solvent Cement Quart
12
2.4
