MULTI-GARD

INSTALLATION PROCEDURES

www.carlonsales.com

3. Replace watertight plugs into terminator and tighten.

4. Apply standard grade solvent cement to terminator male end and insert

into pre-cast bell end. (Install PVC bell fitting in kit if pre-cast bell end is

not available).

5. Use shim enclosed for terminator requiring a connection of Type C (4.35"

O.D.) into a Type 40 (4.50" O.D.) termination.

6. Measure between ends of terminators on opposite ends of vault, and cut

innerduct to length.

7. Solvent cement each coupling into place or use mechanical coupling rated

for use with high speed air blowing systems.

Multi-Gard PVC Trenching

Installation allows Multi-Gard in the trench to be placed one section at a time or

over the trencher for continuous feed. Open trenching with Type C Multi-Gard is

recommended for direct burial or concrete encased applications.

Features:

o

Install one section at a time.

o

Multiple-cells are installed as soon as product is placed.

o

Economical installation with installation speed as fast as the

trencher can dig.

o

Easy installation with standard equipment.

o

Gasketed coupling body prevents conduit pulling apart during

installation.
