MULTI-GARD

INSTALLATION PROCEDURES

www.carlonsales.com

Use a

Type 1 Standard Terminator

also at an entrance where a pre-cast

terminator is not available or a knockout is used:

1. Insert the male end section of Multi-Gard 4 inches past the inside wall of

the vault with print line facing upward.

2. Remove the protective cap from the male end of the Multi-Gard.

3. Remove the watertight plugs and insert the terminator to full depth.

4. Install bell fitting over the end of the Multi-Gard using solvent cement, and

replace plugs.

5. Slide Multi-Gard section until bell fitting is flush with inside, and then seal

entrance as required by job specifications.

Use a

Type 6 Enclosure Terminator

at entrances into metal or non-metallic

enclosures above ground.

1. Remove watertight plugs in order to assure total insertion of the Multi-

Gard innerducts.

2. Install terminators into male end of Multi-Gard to full depth.

3. Replace watertight plugs into the terminator and tighten.

4. Install threaded adapter over end of Multi-Gard using solvent cement.

Insert adapter through enclosure hole and provide 4" locking ring.

5. Use shim enclosed for terminator requiring a connection of type C (4.35

O.D.) termination.
