S70 DeviceNet Servo Installation & Maintenance Manual
2000 BRAY CONTROLS Page 3 of 24
2. Hardware Description
The S70 DeviceNet Servo consists of an electronics module (Figure 1), which includes the
DeviceNet interface, terminal connections to the S70 Actuator, calibration button, DeviceNet
Network Status Indicator, and connections and indicators to features described in Section
Error! Reference source not found..
Figure 1: S70 DeviceNet Servo
Motor Close LED
DeviceNet Connector Motor Power
Power LED
Limit Switch
Network LED
Handwheel
Calibration
Button
Feedback Potentiometer
AC Power
Torque Limit
Switch
Motor Open LED
