S70 DeviceNet Servo Installation & Maintenance Manual
2000 BRAY CONTROLS Page 13 of 24
The selection of the power supply should ensure a tolerance of +24 VDC +/- 1% and current
capability of 0-16 amps.
3.1.4 Network Status LED
This bi
–color (green/red) LED (D17,
Figure 1) indicates the status of the communication link. Refer to table
LED State Description
Off
The S70 is not on–line and has not
completed the Dup MAC_ID test
yet. The S70 may also not be
powered.
Green
The S70 is on-line and allocated to
a master.
Flashing Green
The S70 is on-line and not
connected (not allocated to a
master)
Red
Non recoverable Critical Link
Failure. The S70 has detected an
error that has rendered it incapable
of communicating on the network.
Flashing Red
The Communication Faulted such
as a connection time-out. The S70
can recover from this error.
Table 6: DeviceNet Network LED Indicator
3.1.5 Commissioning
Commissioning is the process of taking the S70 Servo from the on-line state to establishing a
dedicated connection with a master on the network. The S70 Servo supports a Polled network
connection and an Explicit message connection. These connections are supported
simultaneously but only one connection of each type is supported at a time.
When the S70 Servo transitions from the On-line state to the Commissioned state, the Network
LED (Section 3.1.4) will change from flashing green to a solid green. When the Master / Slave
relationship is released, the Network Led will return to a flashing green.
As an example, if the Mac Id of the S70 Servo is added to the scan list of a process controller,
the process controller will establish a Polled Message connection with the S70 and will transition
the S70 Servo to the commissioned state. Once the S70 Servo is commissioned, the process
