Series Mode
fCsRs Dc
π 2 =
Cs Rs
RESISTANCE
Range Accuracy Resolution Test Condition
2Ω 1%＋5 1mΩ 10mArms
20Ω 10mΩ 10mArms
200Ω 100mΩ 1mArms
2KΩ 1Ω 0.1mArms
20KΩ 10Ω 10µArms
200KΩ
1%＋2
100Ω
Series
Mode
1KHz
1µArms
2MΩ 1KΩ
20MΩ
2%＋2
10KΩ
Parallel Mode
1KHz, 0.5Vrms
Accuracy is ± ( % of reading＋number of digits ) and is applied from 10 to
100% of full scale range in parallel mode measurements.
In series mode measurements, the compliance voltage (voltage drop on the
device under test) should be less than 0.2 Vrms.
INDUCTANCE
Range Accuracy Resolution Test Condition
200µH 2%＋2 0.1µH 10mArms, 1KHz
2mH 1µH 10mArms, 1KHz
20mH 10µH 1mArms, 1KHz
200mH
1%＋2
100µH
Series
Mode
0.1mArms,1KHz
2H 1mH
20H 10mH
200H
Not
Specified＊
100mH
Parallel Mode
120Hz, 0.5Vrms
Accuracy is ± ( % of reading＋number of digits ) When D≦0.1.
The accuracy is applied from 10 to 100% of full scale range in parallel mode
measurements.
＊Ranges for reference only.
