Data Sheet
Option 06: Interleaved High-bandwidth Output in Addition to Option 02 (Remove Standard Output)
Available for only AWG7102
Characteristic Description
Output Style Differential
Output Impedance 50 Ω
Connector SMA Front
Zeroing Control On or Off
Amplitude (into 50 Ω)
Amplitude Zeroing On: 250 mV
p-p
to 0.5 V
p-p
Zeroing Off: 500 mV
p-p
to 1.0 V
p-p
Resolution 1 mV
DC accuracy (typical) ±(8.0% of Amplitude + 2 mV) at offset = 0 V
Offset N/A
Pulse Response
Rise/Fall time: (20 to 80%) 45 ps
Overshoot Less than 10% (at 1.0 V
p-p
amplitude)
Bandwidth (-3 dB) (typical) 5.8 GHz
Delay from Marker Output 1.0 ns
Sine Wave (up to 5th harmonic) (20 GS/s clock, 32 waveform points, 625 MHz signal frequency)
Harmonics Distortion Zeroing On: ≤ -40 dBc (0.5 V
p-p
)
Zeroing Off: ≤ -40 dBc (1 V
p-p
)
Nonharmonic Spurious DC to 5 GHz
Zeroing On: ≤ -45 dBc (0.5 V
p-p
)
Zeroing Off: ≤ -45 dBc (1 V
p-p
)
SFDR (typical) (20 GS/s clock, 10 bit DAC operation mode, DC to 10 GHz)
2.5 GHz –
Zeroing On: 30 dB
Zeroing Off: 40 dB
Phase Noise (20 GS/s clock, 625 MHz)
At 10 kHz offset –
Zeroing On: ≤ -85 dBc/Hz (0.5 V
p-p
)
Zeroing Off: ≤ -85 dBc/Hz (1 V
p-p
)
