Arbitrary Waveform Generator — AWG7102 • AWG7101 • AWG7052 • AWG7051
AWG7000 Series Common Features
Characteristic Description
Tektronix DPO7000/TDS5000/6000/7000 (*.wfm),
TDS3000 (*.ISF)
AWG400s/500s/610/615/710/710B (*.wfm, *.pat, *.seq)
Waveform File Import
Capability
Text data file (third-party software creation waveform
data: MATLAB, MathCad, Excel)
S/W Driver for Third-party
S/W
IVI-COM driver
Instrument Control / Data Transfer Ports
GPIB* 1 Remote control and data transfer. (Conforms to
IEEE-Std 488.1, compatible with IEEE 488.2 and
SCPI-1999.0)
Ethernet
(10/100/1000Base-T)* 1
Remote control and data transfer. (Conforms to IEEE
802.3). RJ-45
Computer system and
peripherals
Windows XP Professional, 512 MB SDRAM, 20 GB
removable Hard Drive at rear (available front mount
kit), CD-RW/DVD drive at front, included USB compact
keyboard and mouse
PC I/O ports USB 2.0 compliant ports (6 total, 2 front, 4 rear),
PS/2 mouse and keyboard connectors (rear panel),
RJ-45 Ethernet connector (rear panel) supports
10/100/1000Base-T, XGA out
Display 10.4 inch, LCD color display with touchscreen, 1024
(H) × 768 (V) (XGA)
Power Supply 100 to 240 VAC, 47 to 63 Hz
Power consumption 450 W
Safety UL61010-1,CAN/CSA-22.2, No.61010-1-04,
EN61010-1, IEC61010-1
Emissions EN 55011 (Class A), IEC61000-3-2, IEC61000-3-3
Immunity IEC61326, IEC61000-4-2/3/4/5/6/8/11
Regional Certifications
Europe EN61326
Australia /
New Zealand
AS/NZS 2064
* 1 Supported by MATLAB software through MATLAB Instrument Control Toolbox.
Physical Characteristics
Dimension mm in.
Height 245 9.6
Width 465 18.0
Length 500 19.7
Weight (approx.) kg lb.
Net 19 41.9
Net with Package 28 61.7
Mechanical Cooling Required Clearance
Top and Bottom 2 cm 0.8 in.
Side 15 cm 6 in.
Rear 7.5 cm 3 in.
Environmental
Characteristic Operation Nonoperation
Temperature +10 °C to +40 °C -20 °C to +60 °C
Humidity 5% to 80% relative
humidity (% RH) at up
to +30 °C
5% to 45% RH above
+30 °C up to +50 °C
5% to 90% relative
humidity (% RH) at up
to +30 °C
5% to 45% RH above
+30 °C up to +50 °C
Altitude Up to 3,048 meters
(10,000 feet)
Up to 12,192 meters
(40,000 feet)
Random Vibration 0.27 G
RMS
, 5 to 500 Hz,
10 minutes per axis
2.28 G
RMS
, 5 to 500 Hz,
10 minutes per axis
Sine Vibration 0.33 mm
p-p
(0.013 in.
p-p
)
constant displacement,
5 to 55 Hz
—
Mechanical Shock Half-sine mechanical
shocks, 30 g peak
amplitude 11 ms duration,
3 drops in each direction
of each axis
—
AWG7101
AWG7102
AWG7052
AWG7051 AWG7101
AWG7051
AWG7052 AWG7102
Standard Option 02 Option 06 (Including Option 02)
Characteristic
Normal Out Direct Out High Bandwidth High Bandwidth
without Interleave
High Bandwidth with
Interleave, Zeroing
Off, (Zeroing On)
Maximum Amplitude 2 V
p-p
1 V
p-p
1 V
p-p
1 V
p-p
1 V
p-p
(0.5 V
p-p
)
Minimum Amplitude 50 mV
p-p
50 mV
p-p
500 mV
p-p
500 mV
p-p
500 mV
p-p
(250 mV
p-p
)
Offset ±500 mV N/A N/A N/A N/A
Tr/Tf (20 to 80%) 350 ps 75 ps 45 ps 45 ps 45 ps
Output Bandwidth 750 MHz 3.5 GHz 5.8 GHz 5.8 GHz 5.8 GHz
