Version 05.01, December 2012
Rohde & Schwarz R&S ® FSW Signal and Spectrum Analyzer 17
Inputs and outputs
RF input
Impedance
50 Ω
Connector R&S ® FSW8, R&S ® FSW13 N female
R&S ® FSW26 APC 3.5 mm male (compatible with SMA)
R&S ® FSW43 2.92 mm male (compatible with SMA)
VSWR of R&S ® FSW8 RF attenuation ≤ 4 dB
10 MHz ≤ f ≤ 8 GHz typ. 1.87 14
5 dB ≤ RF attenuation ≤ 9 dB
10 MHz ≤ f < 1 GHz < 1.5, typ. 1.20 14
10 MHz ≤ f < 3.6 GHz < 1.5, typ. 1.31 14
3.6 GHz ≤ f ≤ 8 GHz < 2.0, typ. 1.51 14
RF attenuation ≥ 10 dB
10 MHz ≤ f < 1 GHz < 1.2, typ. 1.09 14
1 GHz ≤ f < 3.6 GHz < 1.5, typ. 1.19 14
3.6 GHz ≤ f ≤ 8 GHz < 2.0, typ. 1.42 14
VSWR of R&S ® FSW13 RF attenuation ≤ 4 dB
10 MHz ≤ f ≤ 13.6 GHz typ. 1.87 14
5 dB ≤ RF attenuation ≤ 9 dB
10 MHz ≤ f < 3.6 GHz < 1.5, typ. 1.25 14
3.6 GHz ≤ f ≤ 13.6 GHz < 2.0, typ. 1.29 14
RF attenuation ≥ 10 dB
10 MHz ≤ f < 1 GHz < 1.2, typ. 1.10 14
1 GHz ≤ f < 3.6 GHz < 1.5, typ. 1.14 14
3.6 GHz ≤ f ≤ 13.6 GHz < 2.0, typ. 1.22 14
VSWR of R&S ® FSW26, R&S ® FSW43 RF attenuation ≤ 4 dB
10 MHz ≤ f ≤ 26.5 GHz typ. 1.87 14
26.5 GHz < f ≤ 40 GHz typ. 2.0 14
40 GHz < f ≤ 43.5 GHz 2.0 (nom.)
5 dB ≤ RF attenuation ≤ 9 dB
10 MHz ≤ f ≤ 3.5 GHz < 1.5, typ. 1.24 14
3.5 GHz < f ≤ 8 GHz < 1.8, typ. 1.26 14
8 GHz < f ≤ 18 GHz < 1.8, typ. 1.39 14
18 GHz < f ≤ 26.5 GHz < 2.0, typ. 1.43 14
26.5 GHz < f ≤ 40 GHz < 2.5, typ. 1.8 14
40 GHz < f ≤ 43.5 GHz 2.0 (nom.)
RF attenuation ≥ 10 dB
10 MHz ≤ f ≤ 3.5 GHz < 1.2, typ. 1.12 14
3.5 GHz < f ≤ 8 GHz < 1.5, typ. 1.19 14
8 GHz < f ≤ 18 GHz < 1.5, typ. 1.25 14
18 GHz < f ≤ 26.5 GHz < 2.0, typ. 1.37 14
26.5 GHz < f ≤ 40 GHz < 2.5, typ. 1.7 14
40 GHz < f ≤ 43.5 GHz 2.0 (nom.)
Setting range of attenuator 0 dB to 79 dB, in 1 dB steps 15
Probe power supply
Supply voltages
+15 V DC, –12.6 V DC and ground,
max. 150 mA (nom.)
Noise source control
Connector
BNC female
Output voltage 0 V/28 V, max. 100 mA, switchable (nom.)
Power sensor
Connector
6-pin LEMOSA female for R&S ® NRP-Zxx
power sensors
14 Typical VSWR performance: performance expected to be met in 95 % of the cases with a confidence level of 95 %, temperature +20 °C to +30 °C,
input set to “DC coupling”. These values are not warranted and are subject to modification if a significant change in the statistical behavior of
production instruments is observed.
15 Mechanical RF attenuator: 5 dB steps. Electronic IF attenuator: 1 dB steps.
