R&S FSH3, R&S FSH6, R&S FSH18 Data Sheet
1145.5973.12 TI.5 E-14
Specification Condition R&S FSH3 R&S FSH6 R&S FSH18
Display units
Logarithmic
Linear dBm, dBIV, dBmV
with transducer also dBIV/m and dBIA/m
IV, mV, V, nW, µW, mW, W
with transducer also V/m, mV/m , IV/m and W/m 2
Traces 1 trace and 1 memory trace
Trace mathematics A-B and B-A (trace – memory trace and memory trace – trace)
Detectors auto peak, maximum peak, minimum peak, sample, RMS
with option R&S FSH-K3
installed in addition average and quasi-peak
Level measurement error
at reference level down to
-50 dB, 20 °C to 30 °C
1 MHz to 10 MHz
10 MHz to 20 MHz
20 MHz to 6 GHz
6 GHz to 14 GHz
14 GHz to 18 GHz
< 1.5 dB, typ. 0.5 dB
< 1.5 dB, typ. 0.5 dB
< 1.5 dB, typ. 0.5 dB
-
-
-
< 2 dB
< 1.5 dB
< 2.5 dB
< 3.0 dB
Markers
Number of markers or delta
markers max. 6
Marker functions peak, next peak, minimum, center = marker frequency,
reference level = marker level, all markers to peak
Marker displays normal (level), noise marker, frequency counter (count)
Trigger free-running, video, external
Audio demodulation AM (video voltage without AGC) and FM
