R&S FSH3, R&S FSH6, R&S FSH18 Data Sheet
1145.5973.12 TI.1 E-14
Specifications
Specifications are valid under the following conditions: 15 minutes warm-up time at ambient temperature, specified environmental conditions met and
calibration cycle adhered to. Data without tolerances: typical values. Data designated as "nominal": design parameters, i.e. not tested.
Specification Condition R&S FSH3 R&S FSH6 R&S FSH18
Frequency
Frequency range 100 kHz to 3 GHz 100 kHz to 6 GHz 10 MHz to 18 GHz
Reference frequency
Aging 1 ppm/year
Temperature drift 0 °C to 30 °C
30 °C to 50 °C 2 ppm
in addition 2 ppm/10°C
Frequency counter
Resolution 1 Hz
Frequency span 0 Hz, 100 Hz to 3 GHz 0 Hz, 100 Hz to 6 GHz 0 Hz, 100 Hz to 18 GHz
1145.5850.13 0 Hz, 1 kHz to 3 GHz - -
Spectral purity
SSB phase noise
f = 500 MHz, 20 to 30 °C
30 kHz from carrier <-85 dBc/(1 Hz) <-85 dBc/(1 Hz)
100 kHz from carrier < -100 dBc/(1 Hz) < -90 dBc/(1 Hz)
1 MHz from carrier < -120 dBc/1 Hz) < -100 dBc/(1 Hz)
Sweep time span = 0 Hz 1 ms to 100 s
span > 0 Hz 20 ms to 1000 s, min. 20 ms/600 MHz
Bandwidths
Resolution bandwidths
(-3 dB) 1145.5850.13 1, 3, 10, 30,100, 200, 300 kHz, 1 MHz
1145.5850.03, .23,
1145.5850.06, .26, .18 In addition 100, 300 Hz
Tolerance 300 kHz ± 5 %, nominal
1 MHz ± 10 %, nominal
