R&S FSH3, R&S FSH6, R&S FSH18 Data Sheet
1145.5973.12 TI.15 E-14
VSWR Bridge R&S FSH-Z2 / R&S FSH-Z3
R&S FSH-Z2 R&S FSH-Z3
Frequency range 10 MHz to 3 GHz 10 MHz to 3 GHz
Impedance 50
VSWR bridge
Directivity
10 MHz to 30 MHz
30 MHz to 1 GHz
1 GHz to 3 GHz
3 GHz to 6 GHz
typ. 30 dB
typ. 30 dB
typ. 25 dB
-
typ. 16 dB
> 20 dB, typ. 28 dB
> 20 dB, typ. 28 dB
> 16 dB, typ. 25 dB
Directivity, corrected
2 MHz to 10 MHz
10 MHz to 3 GHz
3 GHz to 6 GHz
option R&S FSH-K2
typ. 40 dB
typ. 43 dB
-
typ. 40 dB
typ. 40 dB
typ. 37 dB
Return loss at test port
10 MHz to 50 MHz
50 MHz to 3 GHz
3 GHz to 6 GHz
20 dB, typ.
20 dB, typ.
-
> 12 dB, typ. 18 dB
> 16 dB, typ. 22 dB
> 16 dB, typ. 22 dB
Return loss at test port,
corrected
2 MHz to 3 GHz
3 GHz to 6 GHz
option R&S FSH-K2
typ. 35 dB
-
typ. 40 dB
typ. 37 dB
Insertion loss
Test port
Bypass typ. 9 dB
-
typ. 9 dB
typ. 4 dB
