DCR600-20
General/Environmental Mechanical Specifications
Protection and Safety
On / Off Circuit Breaker
Isolation
Output Bleeder
Use AC Breaker to Disconnect DC Rectifier from AC Source
Output.
Ambient Temperature Operating: 0° - 50° C
Storage: -20 ° - 80° C
Chassis
Dimension
( W x H x D)
Cabinet Mount
Regulatory Compliance
CE Approval Pending
IEC61010
IEC61326
Output to chassis
Input to chassis
1200 Vdc / 1600 Vac
1350 Vac
Bleed Resistor Internal, 50KOhm Across DC Out-
put, Heat Sink Mounted.
Safety
EMC
Marking
Type
Width includes Rack Ears: 19” / 483 mm
Depth includes Safety Covers: 11.5” / 292 mm
2U Rack Mount
16.75” x 3.5” x 9.6”
425 x 89 x 245 mm
19” Rack Width
Removable Rack Ears. Requires L Brackets or Slides.
Rack Slide Mounting Holes on Side of Chassis. Con-
tact Customer Service for Rack Slide option.
Terminals Input
Output
Ground
Connection
Cooling
5 Pole Terminal
Compression Block
Phase A, B, C,
Neutral
Chassis Ground
3 Pole Terminal
Block
Rated to 600Vdc,
85Adc.
DC Pos, DC Neg.
AC Input Terminal
Block &
Ground stud on
Rear Panel
Ground Stud near
DC output terminal
to allow ground
EUT as needed
Convection
Front Panel Controls
/ Indicators
On/Off
switch
Banana
Jacks
Circuit Breaker Use AC breaker
to disconnect DC
Rectifier output
from AC Source
Output.
Dual Safety type, 4mm, Sheathed
Female 19 mm Spacing
Red for +DC
Black for -DC
AC Input Connections, 4 Wire + Ground
DC Output Connections
AC Input Terminal Block
DC Output Terminal Block
Dual Safety type, 4mm, Sheathed Fe-
male. 19 mm Spacing.
Red for +DC
Black for -DC
Rear Panel
Connections /
Indicators
Terminal
Blocks
Safety
Covers
Provided
Banana
Jacks
#6DSDCR600-20 Rev0913B
17692 Fitch, Irvine, CA 92614 USA
Phone: +1 949.251.1800
Fax: +1 949.756.0756
Toll Free: 800.854.2433
E-mail: [email protected]
www.pacificpower.com
Ordering Information
Available Models
DCR600-20
Order Example
DRC600-20
• DC Rectifier Chassis
Typical Delivery Items
Ship Kit:
• User Manual on CD ROM
• Input and Output Safety Covers
Model Controller Requirements
DRC600-20 N/A Requires AMX Series Programmable AC Power Source
© 2013 Pacific Power Source, Inc. Subject to change without notice.
Options
Rack Mount Slide Kit. RMS Hardware
19" (483mm) 16.75" (425mm)
2U
3.5”,
89mm)
DCR600-20 DC Output Module
Windows Control Software. Controls Steady
State Settings, Measurements and Output
Sequence Programming
UPC
Manager
UPC Test
Manager
Software
Comprehensive Test Planner and Test
Sequence Management Software. Requires
UPC Manager program.
DC Test
Options
Mil-Std704, RTCA/DO160 ,Airbus, Boeing
