Inputs and Outputs
Supplemental information
Front panel
RF input connector
N-type female, 50 Ω
VSWR
< 1.5:1
300 kHz to 3 GHz, input attenuator ≥ 10 dB
Calibration output
Amplitude
-10 dBm ± 0.3 dB
Frequency
50 MHz
Accuracy
Same as the frequency reference
Connector and impedance
BNC-type female, 50 Ω
Probe power
Voltage/current
+15 V, 150 mA maximum
-12.6 V, 150 mA maximum
RF output connector
N-type female, 50 Ω
Option TG3 installed
USB interface (host)
A plug, version 1.1
Rear panel
10 MHz reference output
Output amplitude
> 0 dBm
Connector and impedance
BNC-type female, 50 Ω
10 MHz reference input
Input amplitude
-5 to +10 dBm
Frequency lock range
± 5 ppm of specified external reference input
frequency
Connector and impedance
BNC-type female, 50 Ω
External trigger input
Input amplitude
5 V TTL level
Connector and impedance
BNC-type female, 10 kΩ
VGA output
VGA analog RGB
31.5 kHz horizontal, 60 Hz vertical sync rates,
non-interlaced
D-sub 15-pin female connector
VGA compatible
640 x 480 screen resolution
LAN TCP/IP interface
10Base, RJ-45 connector
USB interface (device)
B plug, version 1.1
GPIB interface
IEEE-488 bus connector
Optional G01 installed
