4
Supplemental information
Amplitude range
Measurement range 10 MHz to 3 GHz: Displayed average noise
level (DANL) to +30 dBm
(PA OFF) 1 to 10 MHz: DANL up to 23 dBm
100 kHz to 1 MHz: DANL up to 20 dBm
Input attenuator range 0 to 70 dB, in 1 dB steps
Maximum damage level
Average continuous power ≤ +37 dBm Input attenuator setting ≥ 10 dB, 3 minutes
maximum
Peak pulse power ≤ +50 dBm (100 W) For < 10 μs pulse width, < 1% duty cycle,
and input attenuation ≥ 40 dB
DC voltage 50 VDC maximum
Level display range
Log scale units dBm, dBmV, dBμV, dBμA
Linear scale units μV, mV, V, μA, mA, A, μW, mW, W
Marker level readout 0.01 dB Log scale
Resolution 0.01% of reference level Linear scale
Number of traces 4
Detectors Positive-peak, negative-peak, sample,
normal, RMS
Trace function Clear/write, maximum hold, average,
minimum hold, view
Frequency response
10 dB input attenuation, reference: 50 MHz, 20 to -30 °C
200 kHz to 2.0 GHz ± 0.5 dB Preamp off
2.0 to 3.0 GHz ± 0.7 dB Preamp off
1 MHz to 2.0 GHz ± 0.6 dB Preamp on
2.0 to 3.0 GHz ± 0.8 dB Preamp on
Input attenuation switching uncertainty at 50 MHz
Attenuation > 2 dB, preamp off
0 to 60 dB attenuation ± 0.4 dB Relative to 10 dB (reference setting)
Absolute amplitude accuracy
Center frequency 50 MHz, RBW 1 kHz, VBW 1 kHz, amplitude scale log, span 100 kHz, sweep time coupled, peak
detector, signal at reference level
Preamp off ± 0.3 dB Reference level -10 dB, input attenuation
10 dB
Preamp on ± 0.4 dB Reference level -30 dB, input attenuation
10 dB
Amplitude Specifications
