E4411B E4403B/08B
≥ 15 dB
+30 dBm
+30 dBm (1 W)
(1 W)
+50 dBm (100 W)
100 Vdc
+75 dBmV (0.4 W) Option 1DP
0 dBm to 1.5 GHz
46.75 dBmV (1DP)
0 dBm
–3 dBm
–5 dBm
Total power at input mixer
b
50 MHz to 6.7 GHz
6.7 to 13.2 GHz
13.2 to 26.5 GHz
1 dB gain compression Two tone
Peak pulse power
a
DC
voltage
AC coupled 100 Vdc
≥ 5 dB average continuous power;
≥ 30 dB peak pulse power
Input attenuator setting
Average continuous power
Maximum safe input level
Input attenuator range
(5 dB step)
0 - 60 dB 0 - 65 dB
Amplitude range
Measurement range Displayed average noise level (DANL) to maximum safe input level
a. < 10 µs pulse width, < 1% duty cycle.
b. Mixer power level (dBm) = Input power (dBm) minus input attenuation (dB).
Amplitude Specifications
