< –75 dBc, +7.5 dBm TOI
< –75 dBc, +35 dBm SHI (E4411B)
< –60 dBc, +30 dBm SHI
< –70 dBc, +40 dBm SHI
< –80 dBc, +70 dBm SHI
≤ –95 dBc, +85 dBm SHI
100 MHz to 26.5 GHz
Second harmonic distortion
2 to 750 MHz
–40 dBm tone at input mixer
a
10 to 500 MHz
–30 dBm tone at input mixer
a
500 MHz to 1.5 GHz
–30 dBm tone at input mixer
a
1.5 to 2.0 GHz
–10 dBm tone at input mixer
a
> 2 GHz
–10 dBm tone at input mixer
a
Other input related spurious
Inband > 30 kHz offset
Out of band responses < –80 dBc for –10 dBm tone at input mixer
a
< –65 dBc for –20 dBm tone at input mixer
a
Basic analyzer
E4411B/03B/08B
Spurious responses
Third order intermodulation distortion For two –30 dBm signals at input mixer
a
and > 50 kHz separation
Residual responses (Input terminated and 0 dB attenuation)
50 Ω RF input impedance
150 kHz to 1.5 GHz/6.7 GHz
b
< –90 dBm
75 Ω RF input impedance (Option 1DP only
available on ESA-L custom configuration for the E4411B)
1 MHz to 1.5 GHz < –36 dBmV
a. Mixer power level (dBm) = input power (dBm) - input attenuation (dB).
b. Up to 1.5 GHz for models E4411B/03B. Up to 6.7 GHz for model E4408B.
Amplitude Specifications (continued)
