14
Inputs/outputs
Front panel
Input 50 Ω type N (f); 75 Ω BNC (f) (Option 1DP); 50 Ω APC 3.5 (m) (Option BAB)
RF out 50 Ω type N (f); 75 Ω BNC (f) (Option 1DQ)
Probe power +15 Vdc, –12.6 Vdc at 150 mA maximum (characteristic)
External keyboard 6-pin mini-DIN, PC keyboards (for entering screen titles and file names)
Headphone Front panel knob controls volume
Power output 0.2 W into 4 Ω (characteristic)
AMPT REF out 50 Ω BNC (f) (nominal)
IF INPUT (Option AYZ) 50 Ω SMA (f) (nominal)
LO OUTPUT (Option AYZ) 50 Ω SMA (f) (nominal)
Rear panel
10 MHz REF OUT 50 Ω BNC (f), > 0 dBm (characteristic)
10 MHz REF IN 50 Ω BNC (f), –15 to +10 dBm (characteristic)
GATE TRIG/EXT TRIG IN BNC (f), 5 V TTL
GATE /HI SWP OUT BNC (f), 5 V TTL
VGA OUTPUT
VGA compatible monitor, 15-pin mini D-SUB, (31.5 kHz horizontal,
60 Hz vertical sync rates, non-interlaced analog RGB 640 x 480)
IF, sweep and video ports (Option A4J or AYX)
AUX IF OUT BNC (f), 21.4 MHz, nominal –10 to –70 dBm (uncorrected)
AUX VIDEO OUT BNC (f), 0 to 1 V, characteristic (uncorrected)
HI SWP IN BNC (f), low stops sweep, (5 V TTL)
HI SWP OUT BNC (f), (5 V TTL)
SWP OUT BNC (f), 0 to +10 V ramp
GPIB interface (Option A4H) IEEE-488 bus connector
Serial interface (Option 1AX) RS-232, 9-pin D-SUB (m)
Parallel interface
(Option A4H or 1AX)
25-pin D-SUB (f) printer port only
Dimensions and weight for the ESA family of analyzers.
Width to outside of instrument handle 416 mm (16.4 in)
Width to outside of the shipping cover 373 mm (14.7 in)
Overall height 222 mm (8.75 in)
Depth from front frame to rear frame 409 mm (16.1 in)
Depth with instrument handle rotated horizontal 516 mm (20.3 in)
E4411B
Instrument weight
13.2 kg (29.1 lbs)
Shipping weight 25.1 kg (55.4 lbs)
E4403B
Instrument weight
15.5 kg (34.2 lbs)
Shipping weight 27.4 kg (60.4 lbs)
E4408B
Instrument weight
17.1 kg (37.7 lbs)
Shipping weight 31.9 kg (70.3 lbs)
I/O connectivity software IO libraries suite (www.agilent.com/find/iosuite/data-sheet)
General Specifications (continued)
