Basic analyzer
Attenuator setting
0 to 5 dB
10 dB
15 to 60 dB
3 to 6.7 GHz ±1.5 dB
6.7 to 13.2 GHz
13.2 to 26.5 GHz
At reference settings b ±0.4 dB
Overall amplitude accuracyc ± (0.6 dB + absolute frequency response)
Log max cumulative
dB below reference level
RBW ≥ 1 kHz
0 dB reference
> 0 to 70 dB
RBW ≤ 300 Hz (Option 1DR)
span > 0 Hz, auto range on
0 to 98 dB
d
> 98 to 120 dB
Log incremental accuracy
dB below reference level
0 to 80 dB
d
Linear accuracy
±(0.3 dB + 0.01 x dB
from reference level)
±2.0 dB from reference level, characteristic
±0.4 dB/4 dB
Display scale fidelity
±(0.3 dB + 0.01 x dB
from reference level)
±2% of reference level
Absolutea 9 kHz to 3 GHz ±0.5 dB
±2 dB
Absolute amplitude accuracy
±(0.1 dB + 0.01 x attenuator setting)
Frequency response (10 dB input attenuation)
Input attenuator switching uncertainty (at 50 MHz)
±0.3 dB
Reference
a. Frequency response values are referenced to the amplitude at 50 MHz
(20 to 30 °C).
b. Settings are: reference level –25 dBm; (75 Ω reference level +28.75 dBmV);
input attenuation 10 dB; center frequency 50 MHz; RBW 1 kHz; VBW 1 kHz;
amplitude scale linear or log; span 2 kHz; frequency scale linear; sweep time
coupled, sample detector, signal at reference level.
c. For reference level 0 to –50 dBm; input attenuation 10 dB; RBW 1 kHz;
VBW 1 kHz; amplitude scale log, log range 0 to –50 dB from reference level;
frequency scale linear; sweep time coupled; signal input 0 to –50 dBm;
span ≤ 20 kHz (20 to 30 °C).
d. 0 to 30 dB for RBW = 200 Hz.
Amplitude Specifications (continued)
10
