13
E4411B E4403B E4408B
Temperature range
Operating
Storage
Disk drive
Audible noise
sound pressure at 25 ° C
Military specifications
Power requirements
AC operation on (line |)
Standby (line )
DC operation
Data storage (nominal)
Internal
b
External
Memory usage (nominal)
State
State plus 401- point trace
Weight (without options)
13.2 kg 15.5 kg 17.1 kg
29.1 lbs 34.2 lbs 37.7 lbs
Measurement speed
Local measurement rate ≥ 35/s ≥ 30/s ≥ 28/s
Remote measurement and
GPIB transfer
RF center freq tuning time ≤ 90 ms ≤ 90 ms ≤ 90 ms
≥ 30/s ≥ 30/s ≥ 30/s
16 kB
c
20 kB
c
200 traces or states/8.0 MB
3.5 in, 1.44 MB, MS-DOS
Power consumption < 300 W
Power consumption < 5 W
12 to 20 Vdc, < 200 W power consumption
Type tested to the environmental specifications of MIL-PRF-28800F class 3
Type tested to the environmental specifications of MIL-PRF-28800F class 3
90 to 132 V rms, 47 to 440 Hz
195 to 250 V rms, 47 to 66 Hz
EMI compatibility
Conducted and radiated interference is in compliance with CISPR Pub. 11/1990 Group 1 Class A
Conducted and radiated interference is in compliance with CISPR Pub. 11/1990 Group 1 Class B
a
(Option 060)
< 40 dBa pressure and < 4.6 bels power (ISODP7779)
0 to +55 ºC
–40 to +75 ºC
10 to +40 ºC
Basic analyzer
Display resolution d 640 x 480
a. Meeting class A performance during DC operation.
b. For serial numbers < US414400 or MY41440000, 1 MB without Option B72,
8 Mb with Option B72.
c. 401 sweep points. The size of a state will increase depending on the installed
application(s).
General Specifications
d. The LCD display is manufactured using high precision technology.
However, there may be up to six bright points (white, blue, red, or green in
color) that constantly appear on the LCD screen. These points are normal
in the manufacturing process and do not affect the measurement integrity
of the product in any way.
