Offset from CW signal
≥ 10 kHz –93, –95 dBc/Hz
–100, –105 dBc/Hz
–106, –112 dBc/Hz
–118, –122 dBc/Hz
–100, –102 dBc/Hz
–104, –106 dBc/Hz
–113, –116 dBc/Hz
–90, –94 dBc/Hz
≥ 20 kHz
≥ 30 kHz
≥ 100 kHz
Residual FM (peak-to-peak)
Stability
Noise sidebands offset from CW signal with 1 kHz RBW, 30 Hz VBW and sample detector
Specification and typical dBc/Hz applies to all frequencies ≤ 6.7 GHz a, b
Italics indicate typical performance
≥ 30 kHz offset from carrier CW signal
System related sidebands
≤ –65 dBc + 20logN
b
1 kHz RBW,
1 kHz VBW (measurement time) ≤ 150 Hz x N
b
(100 ms)
≤ 30 Hz x N
b
(20 ms), Option 1DR
Basic analyzer
E4411B E4403B/08B
a. Add 20log(N) for frequencies > 6.7 GHz.
b. N = LO harmonic mixing number.
Frequency Specifications (continued)
