13
Arbitrary/sequenced waveforms sample clock control
Characteristics Description
Range 10 MSa/s to 4.2 GSa/s, common or separate for each channel
Resolution 8 digits
Accuracy
Internal reference
≤ 1 ppm from 19 ºC to 29 ºC; 1 ppm/ºC below 19 ºC or above 29 ºC; 1 ppm/year aging rate
External reference Same as accuracy and stability of the external reference. Reference is applied to the
reference input or sample clock input.
Advanced sequencing
Characteristics Description
General Enables the grouping of sequences into scenarios in a way that is similar to how
segments are grouped in a sequence table. Each channel has its own advance
sequencing generator.
ASequence scenario 1 scenario, programmed in advanced sequence table
Dynamic advance sequence
control
Software command or rear panel sequence control input (D-sub, 8-bit lines)
ASequence table length 1 to 1k steps
Step advance control Auto, once and stepped
Once loop counter 1 to 1,000,000 cycles, each sequence
Analog outputs
Characteristics Description
General DC-coupled amplified or direct DAC or AC-coupled amplified output, selectable
Connector type SMA
On/off control Output is turned on or off for each channel independently
