6 PN: 11410-00423 Rev. H ML2430A, ML2480B, ML2490A TDS
Power Meter Specifications ML2430A, ML2480B, ML2490A
System Configuration
Interfaces
ML2430A Series ML2480B Series ML2490A Series
Save/Recall 10 storage registers plus RESET
default settings
20 settings stores
Preset accessible on Front Panel
Offset tables
Secure Mode Wipes non-volatile memory on power up when active.
ML2430A Series ML2480B Series ML2490A Series
Remote Monitoring Yes No
Modem Compatibility Yes No
GPIB
(IEEE–488.2, IEC–625)
> 600 readings/second (per input
channel)
Emulation of Anritsu ML4803,
Agilent 436, 437, and 438
> 400 Readings/second CW Mode [TR3 Mode]
> 350 Readings/second Pulse/Modulated Mode (Continuous Sampling)
[1 µs Pulse, Readout Mode, Display Turned Off, TR3 Mode]
> 10 Profile Transfers/sec Pulse/Modulated Mode (Profile Data)
[200 Points per Sweep, Binary Float Output, 5 µs Trigger Capture Time]
> 20 Readings/sec Pulse/Modulated Mode (Repetitive Sampling)
[50 ns Pulse, Readout Mode, Display Turned Off, TR3 Mode]
Back compatible with ML2480B with additional functionality added.
External Video Output N/A 1/4 VGA
Parallel Printer Port
Compatible with Deskjet 540 and
340 Models (other 500 Series and
300 Series and later are typically
compatible). Canon BJC 80.
N/A
Ethernet
(10/100 BaseT LAN)
N/A
Allows remote control, direct from a PC or Local/Wide-area network,
using Dynamic (Auto) or Static IP assignment.
RS232
Supports software download,
instrument control, and modem
dial-out.
1200, 2400, 4800, 9600, 19200,
38400, 57600 Baud rates are
supported.
Supports software download and Instrument control
1200, 2400, 4800, 9600, 19200, 38400, 57600 Baud rates are
supported.
Cal Factor Voltage Input
(BNC)
Operating Modes:
Display voltage reading on selected
channel
Voltage proportional to frequency
for sensor calibration factor
compensation
Blanking Input -TTL levels only
Selectable positive or negative
polarity
Input Range: 0 V to 20 V
Resolution: 0.5 mV
Control: Adjustable voltage to
frequency relationship
Can be configured for Cal factor correction from synthesiser and
Ext Voltage Voltmeter.
Connection: current probe for PAE applications
External Trigger (BNC) TTL, maximum frequency of
800 kHz
TTL, maximum frequency of 10 MHz
Analogue Output (BNC)
Two outputs configurable to
Log or Lin
Operating Modes:
Selectable channel adjusted for
calibration factors and other power
reading correction settings
Pass/Fail: Selectable TTL High or
Low
Channel output: Near real time
analog Uncalibrated
AC Modulation Output: Output 1
only
Dwell Output: Output 2 only
Output Range: –5.0 V to +5.0 V
Resolution: 0.1 mV
Output 1 can be configured for:
Analog Output
Pass/Fail TTL o/p Limits
Leveling: Sensor Input A
Output 2 can be configured for:
Analog Output
Pass/Fail TTL o/p Limits
Leveling: Sensor Input B
Trigger Output
