Atec Chroma-62000H Series - Manual (Page 6)

ElEctrical SPEciFicatiONS -2
Model 62100H-450 62100H-600 62150H-40 62150H-450 62150H-600
Output Ratings
Output Voltage
0-450V 0-600V 0-40V 0-450V 0-600V
Output Current 0-23A 0-17A 0-375A 0-34A 0-25A
Output Power 10000W 10000W 15000W 15000W 15000W
Line Regulation
Voltage
±0.01% F.S.
Current ±0.05% F.S.
Load Regulation
Voltage
±0.02% F.S.
Current ±0.1% F.S.
Voltage Measurement
Range
90V/450V 120V/600V 8V/40V 90V/450V 120V/600V
Accuracy 0.05% + 0.05%F.S.
Current Measurement
Range
4.6A/23A 3.2A/17A 75A/375A 6.8A/34A 5A/25A
Accuracy 0.1% + 0.1%F.S.
Output Noise & Ripple
Voltage Noise(P-P)
300mV 350mV 60mV 300mV 350mV
Voltage Ripple(rms) 450mV 600mV 15mV 450mV 600mV
Current Ripple(rms) 40mA 30mA 150mA 60mA 45mA
OVP Adjustment Range
Range
0-110% programmable from front panel or digital
Accuracy ±1% of full-scale output
Programming Response Time
Rise Time:Full Load
60ms 60ms 8ms 60ms 60ms
Rise Time:No Load 60ms 60ms 8ms 60ms 60ms
Fall Time: Full Load 60ms 60ms 8ms 60ms 60ms
Fall Time: 10% Load 250ms 250ms 100ms 250ms 250ms
Fall Time: No Load 2.5s 2.5s 1s 2.5s 2.5s
Slew Rate Control
Voltage slew rate
range
0.001V/ms - 7.5V/ms 0.001V/ms - 10V/ms 0.001V/ms - 5V/ms 0.001V/ms - 7.5V/ms 0.001V/ms - 10V/ms
Current slew rate
range
0.001A - 0.1A/ms,
or INF
0.001A - 0.1A/ms,
or INF
0.001A - 1A/ms,
or INF
0.001A - 0.1A/ms,
or INF
0.001A -0.1A/ms,
or INF
Minimum transition
time
0.5ms
Transient Response
Time
Recovers within 1ms to +/- 0.75% of steady-state output for a 50% to 100% or 100% to 50% load change(1A/us)
Efficiency 0.87(Typical)
Drift (30 minutes)
Voltage
0.04% of Vmax
Current 0.06% of Imax
Drift (8 hours)
Voltage
0.02% of Vmax
Current 0.04% of Imax
Temperature Coefficient
Voltage
0.04% of Vmax/°C
Current 0.06% of Imax/°C
All specifications are subject to change without notice. Please visit our website for the most up to date specifications.
