ElEctrical SPEciFicatiONS -1
Model 62075H-30 62050H-40 62050H-450 62050H-600 62100H-30 62100H-40
Output Ratings
Output Voltage
0-30V 0-40V 0-450V 0-600V 0-30V 0-40V
Output Current 0-250A 0-125A 0-11.5A 0-8.5A 0-375A 0-250A
Output Power 7500W 5000W 5000W 5000W 11250W 10000W
Line Regulation
Voltage
±0.01% F.S.
Current ±0.05% F.S.
Load Regulation
Voltage
±0.02% F.S.
Current ±0.1% F.S.
Voltage Measurement
Range
6V / 30V 8V / 40V 90V / 450V 120V / 600V 6V / 30V 8V / 40V
Accuracy 0.05% + 0.05% F.S.
Current Measurement
Range
50A / 250A 25A / 125A 2.3A / 11.5A 1.7A / 8.5A 75A / 375A 50A / 250A
Accuracy 0.1% + 0.1% F.S.
Output Noise & Ripple
Voltage Noise (P-P)
60mV 60mV 300mV 350mV 60mV 60mV
Voltage Ripple (rms) 15mV 15mV 450mV 600mV 15mV 15mV
Current Ripple (rms) 100mA 50mA 20mA 15mA 150mA 100mA
OVP Adjustment Range
Range
0-110% programmable from front panel or digital
Accuracy ±1% of full-scale output
Programming Response Time
Rise Time: Full Load
6ms 8ms 60ms 60ms 6ms 8ms
Rise Time: No Load 6ms 8ms 60ms 60ms 6ms 8ms
Fall Time: Full Load 6ms 8ms 60ms 60ms 6ms 8ms
Fall Time: 10% Load 100ms 100ms 250ms 250ms 100ms 100ms
Fall Time: No Load 1s 1s 2.5s 2.5s 1s 1s
Slew Rate Control
Voltage slew rate
range
0.001V/ms - 5V/ms 0.001V/ms - 5V/ms 0.001V/ms - 7.5V/ms 0.001V/ms - 10V/ms 0.001V/ms - 5V/ms 0.001V/ms - 5V/ms
Current slew rate
range
0.001A - 1A/ms,
or INF
0.001A - 1A/ms,
or INF
0.001A - 0.1A/ms,
or INF
0.001A - 0.1A/ms,
or INF
0.001A - 1A/ms,
or INF
0.001A - 1A/ms,
or INF
Minimum transition
time
0.5ms
Transient Response
Time
Recovers within 1ms to +/- 0.75% of steady-state output for a 50% to 100% or 100% to 50% load change(1A/us)
Efficiency 0.87(Typical)
Drift (30 minutes)
Voltage
0.04% of Vmax
Current 0.06% of Imax
Drift (8 hours)
Voltage
0.02% of Vmax
Current 0.04% of Imax
Temperature Coefficient
Voltage
0.04% of Vmax/°C
Current 0.06% of Imax/°C
All specifications are subject to change without notice. Please visit our website for the most up to date specifications.
