Production test
Reduce production test factors
• Increase test throughput
The precision LCR meter family reduces testing costs
by providing accurate high throughput testing.
• Interface easily to handlers
Built-in comparator, cable compensation 1 , and interfaces 2
permit system integration.
• Minimize operator error
Instrument state storage minimizes costly setup errors.
Quality assurance
Automated quality assurance
• Reduce your system development time
The Agilent 4284A and Agilent 4285A are designed to be used
as elements in systems. This means GPIB, programming,
and the ability to interface with scanners
3 .
• Painlessly integrate the system
GPIB and a scanner 3 interface allow the instruments to easily
integrate into system configurations.
• Leverage your programming experience
Learning to program one instrument automatically means
you learn both.
One LCR meter family
for your product’s life cycle
Research and development
Research tomorrow’s electronic components now
• Increase measurement confidence
The basic accuracies are:
Agilent 4284A 0.05% and Agilent 4285A 0.1%.
• Detect 1 ppm changes
The 6-digits of resolution permit you to measure differences
in materials not detectable before.
• Fit the instrument to your test needs
For low frequency applications the Agilent 4284A is the ideal
tool. For testing at RF frequencies the Agilent 4285A is the
best solution.
Material design
Design and test new materials
• Material test fixtures
For accurate permittivity and dissipation factor measurements
of solid dielectric materials, the 16451B dielectric test fixture
is provided. The 16452A liquid test fixture is provided for the
permittivity measurements of liquids with minimal conductivity.
• Sample program
By using the sample program in the operation manual of
16451B, complex permittivity can be calculated rather easily
and instantly. In addition, with the use of a spreadsheet soft
ware, the frequency response of permittivity can be displayed
in a graph.
1. For 4284A, need Option 4284A-006
2. Choose the combination from Option 4284A/4285A-201, 4284A/4285A-202, or
4284A/4285A-301
3. Need Option 4284A/4285A-301
